MVC Design Pattern + Clean ABAP

The Appetizer

Source: https://www.instructables.com/How-To-Patch-Your-Clothes/

The Main Course

The Controller Class Definition

  1. Use nouns for Classes and verbs for Methods
    The Class name is zcl_controller (noun) while the Method name is get_object (verb)
  2. Avoid encodings especially hungarian notation and prefixes
    I usually used prefix for variable such as gt_ (global tables), im_ (import), ex_ (export), etc. Instead from the code above I only use name as the importing variable name with no longer using prefix.

The Controller Class Implementation

  1. Avoid encodings especially hungarian notation and prefixes
    Variable name without prefix as explained above
  2. Use class-based exceptions
    I used some standard exception classes to mitigate error when creating object and casting.
  3. Use |{ }| to assemble text
    I used to concatenate strings but this approach is simpler and tidier. The implementation of this principle can be seen in how I assemble text for the message error in the exception handling.

The Model Class Definition

  1. Use nouns for Classes and verbs for Methods
    The Class name is zcl_model (noun) while the Method name is get_sales_docs (verb)
  2. Avoid encodings especially hungarian notation and prefixes
    I usually used prefix for variable such as gt_ (global tables), im_ (import), ex_ (export), etc. Instead, from the code above I only use doc_date as the importing variable name with no longer using prefix.

The Model Class Implementation

  1. Avoid encodings especially hungarian notation and prefixes
    Variable name without prefix as explained above.
  2. Use plural
    I use this principle to differentiate more between singular line of data (work area) or plural (internal table). Hence for itabs I chose the name sales_doc_headers, sales_doc_items, and sales_docs (plural) while the work areas are sales_doc_header, sales_doc_item, and sales doc (singular)
  3. Prefer insert into table to append to
    On the line 28, INSERT INTO TABLE is used instead of APPEND for adding data from Work Area to the Internal Table
  4. Prefer is not to not is
    On the line 12, IS NOT INITIAL is used instead of NOT IS INITIAL.
  5. Avoid obsolete language elements
    On the line 8 and 14, the @-escaped "host" variables make a little clearer what's a program variable and what's a column in the database

The Controller ( Report Driver Program)

  1. Use constants instead of magic numbers
    model_name and report_name are created as constants instead of assign it as string directly for Model Name and Report Name. This actually still can be improved by maintaining the hardcode values in TVARVC Table. More on this here: https://blogs.sap.com/2021/05/26/avoid-hardcoding-in-sap-by-tvarvc-or-setleaf/
  2. Use class-based exceptions
    I used some standard exception classes to mitigate error when creating object and calling method.
  3. Use |{ }| to assemble text
    I used to concatenate strings but this approach is simpler and tidier. The implementation of this principle can be seen in how I assemble text for the message error in the exception handling.
  4. Do not chain up front declarations
    As the Clean ABAP suggests : “The Chaining suggests the defined variables are related on a logical level. To consistently use it, you would have to ensure that all chained variables belong together, and introduce additional chain groups to add variables. While this is possible, it is usually not worth the effort. Chaining also needlessly complicates reformatting and refactoring because each line looks different and changing them requires meddling with colons, dots, and commas, that are not worth the effort.” Hence the way the Constants initialized on the line 3 and 4.
  5. Prefer inline to up front declarations
    On line 13, this is the preferred way to initiate variable and assign the value to it with one command. If you follow these guidelines, your methods will become so short (3–5 statements) that declaring variables inline at first occurrence will look more natural.

The Model ( Report Driver Program)

  1. Avoid encodings especially hungarian notation and prefixes
    I usually used prefix for variable such as gt_ (global tables), im_ (import), ex_ (export), etc. Instead, from the code above I only use doc_date as the exporting variable name with no longer using prefix.
  2. Use class-based exceptions
    I used some standard exception classes to mitigate error when calling method.
  3. Use |{ }| to assemble text
    I used to concatenate strings but this approach is simpler and tidier. The implementation of this principle can be seen in how I assemble text for the message error in the exception handling.

The View ( Report Driver Program)

  1. Don’t call static methods through instance variables
    Displaying ALV Report using the static Class CL_SALV_TABLE. Hence to use it, creating the instance of the class in unnecessary. A static method is attached to the class itself, and calling it through an instance variable is a potential source of confusion.
  2. Prefer inline to up front declarations
    On line 8, 15 and 19, are the preferred way to initiate variable and assign the value to it with one command. If you follow these guidelines, your methods will become so short (3–5 statements) that declaring variables inline at first occurrence will look more natural.
  3. Use class-based exceptions
    I used some standard exception classes to mitigate error when there is an ALVrelated error.
  4. Use |{ }| to assemble text
    I used to concatenate strings but this approach is simpler and tidier. The implementation of this principle can be seen in how I assemble text for the message error in the exception handling.
  5. Prefer functional to procedural calls
    On line 16, 17, 20 and 22 are the preffered way to call method instead of the needlessly longer CALL METHOD command.
  1. Use descriptive names
  2. Use same abbreviations everywhere
    People will search for keywords to find relevant code. Support this by using the same abbreviation for the same thing. For example, always abbreviate “detection object type” to “dobjt” instead of mixing “dot”, “dotype”, “detobjtype” and so on.
  3. Avoid noise words such as data info object
  4. Keep methods small

--

--
